DR538
Characteristics
Drive wheel, for Regional road using;
Suitable for the medium and long distance on the good road surface; With excellent driving power and anti-wear character;
Longer mileage and outstanding heat dissipation.
- 11R22.5
-
- Loading Index148/145M
- Ply Rating16
- Standard Rim8.25
- Tread Depth(mm)21.0
- Section Width(mm)279
- Overall Diameter(mm)1054
- Max Load(kg)3150/2900
- Max Load(lbs)6944/6393
- Pressure(kPa)830
- Pressure(psi)120
- 12R22.5
-
- Loading Index152/149L
- Ply Rating18
- Standard Rim9.00
- Tread Depth(mm)22.0
- Section Width(mm)300
- Overall Diameter(mm)1085
- Max Load(kg)3550/3250
- Max Load(lbs)7830/7160
- Pressure(kPa)930
- Pressure(psi)135
- 295/80R22.5
-
- Loading Index152/149M
- Ply Rating18
- Standard Rim9.00
- Tread Depth(mm)20.0
- Section Width(mm)298
- Overall Diameter(mm)1044
- Max Load(kg)3550/3250
- Max Load(lbs)7830/7160
- Pressure(kPa)900
- Pressure(psi)130
